CHLB 40B Automatic play dough cup filling and robotic hand packing machine
Specially for play dough's cup package production.
Machine Details :
(1) Cup feeding: to feed the cups automatically by additional feeder in the packing machineline.
(2) Cup conveyed by metal chain: machine will convey the cups by pushers of the chain.(3) Cup sterilization: to sterilize for the cups.
(4) Feeding product: Worker pull the plasticine into this hopper, screw will feed the plasticine tothe extruder device.
(5) Extruding: to extrude the plasticine.
(6) Shape forming: to make the different size of plasticine by the different mould.
(7) Cup filing:. Cup stop under this device, and finished plasticine will fill into the cup.(8) Cup conveyed by metal chain: After filign, the cups still move ahead.
(9) Cups moving by mechanical arm: mechanical arm carry cups to the sealing/cappingmachine
(10) Film sealing: Each cup will first too use the film to sealing the cup mouth.(11) Cup capping: Then capping the cup mouth.
(12) Feeding cap: to feed the caps one by one above the cup.
Machine Application :
Mahine Features:
- Extruding mud, feeding, cutting, putting cups, sealing film(or capping) all in onemachine.
- Easy operation and clean.
- Accurate length cutting.
- Food grade stainless steel contact parts.
- Robotic hand, accurate positioning.
- Easy to change product weight.
- 7" Touch screen.
- Full automatic operation, avoid human intervention.
Machine Specifications :
| Machine Dimension | L3500*W1OO0*H2200mm |
| Machine Weight | 1000KG |
| Power | 220V,50HZ,3kw |
| Air pressure | 0.6~0.85Mpa |
| Gas consunption | 0.45 M³/min |
| Capacity | 30~40cups/min |
| Packing Type | Cup |
| Packing Range | 30-120g |
FAQ :
Q1: Can you send me the installation video of this machine?
A1: Yes, please check the link for this video
Q2: What is the material of contact food/material parts?
A2: The contact food/material parts are made of 304# stainless steel. The machine body can be 304# stainless steel or carbon steel.
Q3: Can this machine make different bag sizes?
A3: One former can make one bag width, and the bag length can be adjustable within a range. It should be ordered an extra former if you want to make the other bag width.
Q4: Does your company accept OEM?
A4: Yes, we have a professional design and technical team to accept customization.
Q5: When you can deliver the machine after the order is placed?
A5: We usually can arrange shipment after 30-40 working days, but it depends on the quantity of the products.
Q6: How about your warranty?
A6: We provide 13 months warranty, starts from the issue date of bill of lading.
Q7: What can you provide after service?
A7: We can provide machine testing video and pictures before delivery, English manual, some free spare parts, installation in clients' factory and technical training.
Welcome to visit our factory to view more details.
